Quality Waste Wood Single Shaft Shredder

Quantity:
  • ENERPAT

Quality Single Shaft Shredder For Waste Wood

Our reliable industrial wood shredders and wood grinders ensure the production of a homogeneous granulate. This can be used for your in-house wood chip furnace, biogas plant, biomass co-generation plant and the production of wood briquettes. And this reduction in size also reduces your disposal, transport and storage costs. Regardless of how you are planning to use the wood chips, we will configure the wood grinder or chipper for woodworking scrap exactly according to your needs.


We offer a large selection of longevity wood shredders for carpenters, joineries and the wood processing industries, with various working widths, rotor diameters and drive capacities. The wood waste grinders can shred all mixed woodworking waste such as offcuts, veneers, pallets, solid timber, particleboards and MDF boards. The possible granulate sizes usually range from 12 to 80 mm. Regardless of whether you need a compact, small wood shredder or have specific needs with a conveyer system, we will always find the right wood recycling equipment for you!



Applications

Off cutts

Shredding cap timber or off cuts is quite a challenge for wood grinders. The machine needs to be particularly robust and sturdy. We offer shredding solutions specifically designed for this "very hard" application.



Solid timber

A sturdy and reliable cutting system is required for shredding solid timber. We offer wood waste grinders that are tested and proven in processing all types of solid timber


Particle board and MDF boards

Our single-shaft shredders are especially well suited for shredding all types of board materials. Both particle boards and MDF boards are shredded reliably and efficiently. We can always offer a trouble free size reduction solution depending on the board size and the desired throughput rate and granular size.


Wood splinters

UNTHA four-shaft shredders are well proven in the shredding of long wood splinters. Thanks to the special cutting unit configuration, the splinters are independently "pulled" into the machine and reliably shredded. Our rotary shears are particularly sturdy and have a long service lif


Pallets

Shredding pallets with metal inclusions (nails, screws, clamps, ...) are no problem at all for the robust UNTHA cutting unit. After shredding, the metal pieces can be easily removed with a magnet. We offer customized comprehensive solutions for shredding pallets: From shredding machine and discharge unit to metal separation - all from one source!


Production waste from the wood processing industries

When shredding woodworking waste from the wood processing industry, it is very important for the shredding machines to maintain high availability particularly in multi-shift operation. Our wood waste grinders are very reliable and are particularly designed for multi-shift operation. Moreover, the low maintenance requirements further increase availability.


Veneers

Shredding thin veneers appears to be very easy at first glance. But correct wood grinder configuration is a decisive factor here. With our spiky shaped pusher infeed system we offer you a customized shredding machine especially designed for shredding veneer.


Bark

Two shredding systems are available for shredding bark. Our rotary shears work especially well with wet bark, while our LR single-shaft series is the preferred system for dry and hard bark


Official Photos

MSA-F600-2

1
2
3

Rotor

Genox-Vision-1

  • Chevron rotor design

  • Rotor knives manufactured from special heat treated DC53 steel. They can be rotated and used on four edges before replacement

  • Long life fixed blades that can be adjusted to maintain cutter clearance

  • Wear resistant coating. Optional for applications involving abrasive material such as fibre glass

Screen Basket

Genox Vision Series Screen Basket

  • Quick change screens for accurate particle size control (sizes 12-100mm)

  • Safety limit switch fitted to screen access door to prevent machine operation whilst access door is open

  • Cylinders access door opener mounted on V800-V1500 series for easy opening and access

  • Star screen is available as an option for thin and/or flexible material such as film

Bearings

Genox Vision Series Bearings

  • Oversized, high quality spherical shaft bearings are isoloated from the cutting chamber to prevent product migrations through the grease seals

  • Bearing housing integral machined to ensure the longevity of the bearings

  • Rotor water cooling. Optional water cooling through the bearing housing to the rotor

Ram

Genox Vision Series Ram

  • Segmented shredding chamber floor with brass guides

  • Machined, one-piece segmented floor

  • Advanced adjustable sealing system for the pushing unit

  • Fines discharge chute to the collect the fines during shredding and to protect the  hydraulic power pack

Drives

Genox Vision Series Drives

  • Electric drive motors configured for Star/Delta starting. Fluid coupling mounted on V1200 and V1500

  • Heavy duty reduction gearbox mounted directed onto the rotor shaft

  • Shock absorbing gearbox mountng arrangement to reduce stress on drive components

Hydraulic System

Genox Vision Series Hydraulic System

  • Twin speed hydraulics, faster speed for backwards to maximise the shredding throughput

  • Integrated oil/air cooler to maintain temperature for continuous operation

  • Optional cover insulator for applications that may eject hazard particles such as wood shredding.

Control Panel

Genox Vision Series Control Panel

  • Standalone electrical control panel with Siemens PLC control system and Schneider electrical components.

  • Manual and automatic controls for rotor direction and hydraulic force feeding device

  • Intelligent programming whereby the motor automatically reverses on overload and stops when the machine is idle


Applications

1
2
3

 ·   Plastics
Mouldings, Purgings/Lump, Profiles, Films etc.

 ·   Timber/Wood
 Pallets, Joiners Waste, Green Waste etc.

 ·   Paper & Cardboard
Confidential Documents, Production Waste, Packaging Materials etc.

 ·   Copper Cable
Household, Telecoms and Industrial Cables including S.W.A

 ·    Aluminum
Used Beverage Cans (UBC's), Swarf, Cables etc.

 ·   Textiles
Carpet (Rolls & Tiles), Garments etc.

 ·   Security Destruction
Counterfeit Items, Faulty Goods, Out of Date Stock etc.
