High Speed Scrap Pe Film Single Shaft Shredder

Wood pallet shredders MSB-G1200 two shafts shredder and MSA-F1500 single shaft shredder are high performance shredders for shredding pallets, wood waste and residual timber.

Quantity:
  • ENERPAT

High Speed Scrap Pe Film Single Shaft Shredder

The before shredding materials of Plastic laminated film shredder are normally presented as laminated film sheets. A sheet of laminating film is composed of several plastic layers. Normally the harder layer is on the outside and the softer layer is on the inside.  What kind of plastic is used in laminating film? The harder outer layer is usually made from PET plastic (Polyethylene Terephthalate) and the softer inner layer is made out of EVA plastic (Ethylene-Vinyl Acetate). Occasionally a combination of PET plastic, PE (Polyethylene Plastic) and EVA plastic are all used together.


There are several type of laminating films which includes School Laminating Film, Standard Laminating Film,   Professional Laminating Film,   Digital Low-Melt Laminating Film and Pressure Sensitive (Cold) Laminating Film.

Plastic laminated film is widely used for framing and packing things. If these huge amount of plastic laminated film waste is not right disposed and go to landfill directly, we cannot imagine how much white pollution is created. Luckily plastic laminated films are considered “green” products as the films and their resins can be 100% recycled and re-used. For example, we can produce plastic pellets for various applications. Today, more and more people are involved in such plastic recycling. They are working on improving the technology to achieve zero-landfill for these plastic laminated films waste.


A lot of awareness have been created among the people on the plastic recycling and reusing. Many recycling machines are involved in plastic laminated film recycling. Plastic laminated film shredder is used for the size reduction of plastic laminated films.


How does plastic laminated film shredder work?

The mechanism behind the plastic laminated film shredder is similar to that of the normal shredder,

These three steps are the most important and fundamental one in shredding.

Precautionary measures to be taken during plastic laminated film shredder operation:

When it comes to operating a machine, a lot of safety measures have to follow and should concentrate on a number of things like,


The operator should wear the safety suit whenever working with the shredder.

He/ she should know the dos and don’ts of the machine.

How much will plastic laminated film shredder cost?


The price of plastic laminated film shredder can vary from place to place. A lot of things will be considered while buying a machine, for example its power, holding capacity, hydraulic parts, electrical usages, brands, transportation, installation and so on. One thing is sure that is the more advanced the machine, the more useful and expensive it will be

Official Photos

MSA-F600-2

1
2
3

Rotor

Genox-Vision-1

  • Chevron rotor design

  • Rotor knives manufactured from special heat treated DC53 steel. They can be rotated and used on four edges before replacement

  • Long life fixed blades that can be adjusted to maintain cutter clearance

  • Wear resistant coating. Optional for applications involving abrasive material such as fibre glass

Screen Basket

Genox Vision Series Screen Basket

  • Quick change screens for accurate particle size control (sizes 12-100mm)

  • Safety limit switch fitted to screen access door to prevent machine operation whilst access door is open

  • Cylinders access door opener mounted on V800-V1500 series for easy opening and access

  • Star screen is available as an option for thin and/or flexible material such as film

Bearings

Genox Vision Series Bearings

  • Oversized, high quality spherical shaft bearings are isoloated from the cutting chamber to prevent product migrations through the grease seals

  • Bearing housing integral machined to ensure the longevity of the bearings

  • Rotor water cooling. Optional water cooling through the bearing housing to the rotor

Ram

Genox Vision Series Ram

  • Segmented shredding chamber floor with brass guides

  • Machined, one-piece segmented floor

  • Advanced adjustable sealing system for the pushing unit

  • Fines discharge chute to the collect the fines during shredding and to protect the  hydraulic power pack

Drives

Genox Vision Series Drives

  • Electric drive motors configured for Star/Delta starting. Fluid coupling mounted on V1200 and V1500

  • Heavy duty reduction gearbox mounted directed onto the rotor shaft

  • Shock absorbing gearbox mountng arrangement to reduce stress on drive components

Hydraulic System

Genox Vision Series Hydraulic System

  • Twin speed hydraulics, faster speed for backwards to maximise the shredding throughput

  • Integrated oil/air cooler to maintain temperature for continuous operation

  • Optional cover insulator for applications that may eject hazard particles such as wood shredding.

Control Panel

Genox Vision Series Control Panel

  • Standalone electrical control panel with Siemens PLC control system and Schneider electrical components.

  • Manual and automatic controls for rotor direction and hydraulic force feeding device

  • Intelligent programming whereby the motor automatically reverses on overload and stops when the machine is idle


Enerpat Single Shaft Shredder Details


Photos (MSB-G1200 Two Shaft Shredder)



WASTE PE FILM

1

ModelG1200


F1500


Dimension (L x W x H) (mm)3580 × 1965 × 2202800 × 2750 × 2130
Hopper Opening (L x H) (mm)1200 × 7252100 × 1430
Discharge Height (mm)875565
Rotation Diameter (mm)Φ430Φ400
Operation Length (mm)12001400
Rotation Speed (RPM)1580
Ram (mm)N815
Screen Size(mm)NΦ40
Number of Rotor Knives3078+4
Number of Counter KnivesN3+3
Main Drive (kW)4475
Hydraulic Power Pack (kW)N5.5
Weight (kg)Approx5120Approx7300
