Our fully automatic horizontal balers are an automated version of our horizontal balers, able to process high volumes of recyclable materials such as paper, cardboard and plastics, ideal for companies with a large amount of daily waste to handle.
Materials are pressed into stable, high-density bales by our fully automatic balers, which are easy and safe to stack, requiring less storage space. The length and weight of bales is selectable, with bales being tied automatically when the selected length is reached.
Our fully automatic horizontal balers are CE marked and designed with customer requirements in mind, making your waste management a simple and cost efficient process.
Enerpat Direct supply a full range of fully automatic horizontal balers to handle all the standard materials such as cardboard, soft plastics (shrink-wrap, plastic sheeting), PET bottles as well as hard plastics, aluminium and steel cans and even difficult materials such as RDF (Refuse Derived Fuel).
Fully automatic balers are required when a throughput over 2 tonnes per hour is needed. Tying-off of bales is carried out automatically.
Enerpat’s fully automatic horizontal baler, ranging from 20 tons to 200 tons pressure force, has a processing power of up to 25 tons per hour. It is perfect for recyclers handling large daily amount of soft waste such as cardboard/OCC (popular as cardboard baler or OCC baler), paper, plastic film, natural fiber, textile waste, soft plastic package, etc. This fully automatic baling machine is also our flagship line of horizontal open end baling machines. It combines advanced computer controlled operations with reliable hydraulics and seamless heavy duty frame construction. Troubleshooting of this automatic line baling machine can be controlled from the Mitsubishi PLC, and with Remote Control on PLC system, we are able to extend our technical assistance no matter where the machines are. All of these advanced features do not get in the way of operation – this is very simple baling machine to run.
Bale weight and length of this auto-tie horizontal baler can be programmed and controlled through a easy-to-use touch screen panel according to your specific transportation arrangement, making it ideal to maximize your container loading. For example, HBA120-110130 model horizontal baling press, is able to produce super dense rectangular bale up to 1200kg each, with bale size up to 2300mm x 1100mm x 1300mm. You can load up to 26 tons of OCC bales produced by this machine into a 40’HQ container without the need to turn the bales around from one side to another. Also rectangular bale is much easier for storage and transportation compared to round bale.
with feeding conveyor to fill the baler evenly and continuously
we install conveyor for all our auto horizontal baler
the thickness of the steel plate for the conveyor at least 3mm
all conveyors are made by enerpat
Special Press Ram
with E-ECO special press ram to compact bulky materials
Wide Touch Screen with High Resolution. Within the control unit is the capability of selecting the correct settings through the programmable logistic controller. You therefore can easily perform any fine-tuning, making the machine optimized to work perfectly for your requirements.
Independent Cooling System
we supply 3 hydraulic system cooling choice
(1) Industrial cooling machine,like our Home Air Conditioning，we can set one ideal temperature for the hydraulic system,once the temperature exceed the setted data,the machine will Alarm for warnings.which system also support 24 hours running.
(2) Electrical cooling fun
(3) Water cooling machine
Tying Bale System 1
we buy the cutting blades for the auto tying bale system from Germany directly which can cut the steel baling wire fast in seconds. also the good quality blades material make sure which keeps for long time,save the spare parts cost for our customers.
Tying Bale System 2
The auto tying bale system designed by Mr Mark engineer,who research the auto tying bale system for more than 20 years for USA and Europe baler company.also the SKF bearing which support the relibale running of this device.
Top Press Ram
Unique Bale Density Control system automatically and continuously regulates the tensioning force exerted on the baled material. For "Slick materials", the Bale Density control system creates greater squeezing force to achieve the highest bale density possible. No adjustments are required.
|Model ||Bale Size |
|Bale Weight |
|Motor Power |
|Machine Size |
