Scrap Paper Two Shaft Shredder MSB-E3

The E3 is a rugged shredder with a particularly high throughput performance. Thanks to its special design this shredding machine is particularly well suited for waste paper and cardboard waste. Special sealings protect critical components from aggressive plant and food acids. Furthermore, the uncomplicated machine technology keeps your maintenance expenditures to a minimum.
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Product Overview

Scrap Paper Two Shaft Shredder MSB-E3


The E3 is a rugged shredder with a particularly high throughput performance. Thanks to its special design this shredding machine is particularly well suited for waste paper and cardboard waste. Special sealings protect critical components from aggressive plant and food acids. Furthermore, the uncomplicated machine technology keeps your maintenance expenditures to a minimum.


The E3 is a very efficient 2-shaft shredder that is perfectly designed for paper waste and their specific characteristics. The precise cutting unit in connection with a stripping system ensure exact cutting and prevents jamming.


These shredders were equipped with a special mechanical seal that protects the shaft bearings and the gears from dirt and acids. This extends the service life and reduces maintenance expenditures. The E3's low noise and dust emissions thanks to the low speed of both shafts provides an additional advantage.


The two-shaft shredder can be optimally adjusted to your operating situation with various cutting unit widths, motors and many other technical options. We also offer comprehensive solutions from one source!


Official Photos

IMG_0133

IMG_0130

IMG_0131

IMG_0132

Applications

Mixed waste
Hard plastics
Medical Scraps
Organic waste
Paper/cardboard/carton/books/newspapers


Technical Data Sheet

Shredding Chamber(mm) 250x250
Power Supply  1x380V 50Hz 110A
Motor Power (kW) 3.0
Noise Level (dB) 65-68
Hopper Size(mm) 500x500
Blade Quantity  22
Blade Width (mm) 20
Gear Oil Volume(l) 18
Gear Oil Type  U.S Mobil 600XP
Machine Length(mm) 1000
Machine Width(mm) 600
Machine Height(mm) 1661
Machine Weight(t) 0.4
Package  Wood Box Package


Application

  MSB-7.5 Shredder-1

MSB-7.5 Shredder-2
