Economy Waste Tire Two Shaft Shredder

Quantity:

Waste Tire Two Shaft Shredder

G Series Twin Shaft Shredders are extremely high torque, high throughput, rotating shear type size reduction machines often used for pre-shredding of large volume or high strength materials which may contain contamination. The unique modular split chamber design, provides excellent access to key components therefore reducing maintenance downtime and service costs. This is a huge advantage when comparing machines of this size.

Official Photos

MSB-60 双轴破碎机

MSB-60废钢破碎机

Features

  • Slow Speed High Torque Shredding Principle

  • Low Dust and Low Noise Operation and Rugged Low Maintenance Design.

  • Shock absorbing shaft couplings between gearboxes and blade shafts reduces operational stress.

  • High Strength Cutters and Spacers manufactured from high quality, heat treated steel alloys are suitable for shredding tough materials.

  • Individual Cleaning Fingers mounted to the chamber sidewalls ensure quick discharge of shredded materials.

  • Modular Chamber Design with split endplates and bearing housings enables quick access to key components.

  • Advanced Adjustable Sealing System for the bearings.

  • Stand Alone Electrical Control Panel with Siemens PLC Control System.

  • Tested, Approved and Certified to the applicable CE safety standards.



ModelG300G400G600G800
Dimension (L x W x H) (mm)1500 x 1225 x 18501600 x 1225 x 18502530 x 1270 x 18502710 x 1270 x 1850
Hopper Opening (L x H) (mm)300 x 480400 x 480600 x 480800 x 480
Discharge Height (mm)600600640640
Rotation Diameter (mm)Φ276Φ276Φ276Φ276
Rotation Speed (RPM)13/7.713/7.71414
Number of Blades (PCS)1510+1015+1520+20
Blade Width (mm)20202020
Main Drive (kw)7.57.55.5+5.57.5+7.5
Hopper Volume(L)480550650750
Weight(kg)Approx 1370Approx 1470Approx 2100Approx 2300
ModelG800TG1000G1200
Dimension (L x W x H) (mm)3050 x 1850 X 22003320 x 1890 X 22003580 x 1965 x 2200
Hopper Opening (L x H) (mm)800 x 7251000 x 7251200 x 725
Discharge Height (mm)875875875
Rotation Diameter (mm)Φ430Φ430Φ430
Rotation Speed (RPM)151515
Number of Blades (PCS)10+1013+1215+15
Blade Width (mm)404040
Main Drive (kw)15+1518.5+18..522+22
Hopper Volume(L)95011301360
Weight(kg)Approx 4010Approx 4520Approx 5120


ModelG1300G1600
Dimension (L x W x H) (mm)4900 x 2210 x 26005150 x 2210 x 2600
Hopper Opening (L x H) (mm)1300 X 8801600 X 880
Discharge Height (mm)970970
Rotation Diameter (mm)Φ515Φ515
Rotation Speed (RPM)5.4-155.4-15
Number of Blades (PCS)13+1316+16
Blade Width (mm)5050
Main Drive (kw)37+3745+45
Hopper Volume(L)17002000
Weight(kg)Approx 11000Approx 11400
ModelG1500G1800
Dimension (L x W x H) (mm)6350 x 2600 x 40007000 x 3050 x 4000
Hopper Opening (L x H) (mm)1500 x 14401800 x 1440
Discharge Height (mm)15501550
Rotation Diameter (mm)Φ750Φ750
Rotation Speed (RPM)5.4-125.4-12
Number of Blades (PCS)15+15 (50mm)/ 10+10 (75mm)12+12 (75mm)/9+9(100mm)
Blade Width (mm)50/7575/100
Main Drive (kw)55+5575+75
Hopper Volume(L)36004000
Weight(kg)Approx 27700Approx 32450
